Onkyo Icon M-80 Stereo Power Amplifier

Onkyo Icon M-80 Stereo Power Amplifier

With a three-stage Inverted Darlington Amplifier and great attention paid to vibration supression, the Onkyo M-80 Power Amplifier powerfully drives large speakers to deliver dynamic full range audio that will captivate and move you.

Product Highlights:

• 130 watts per channel into 8 ohms (20-20,000 Hz) at 0.08% THD with 2 channels driven (FTC Power Output Rating)
• 200 watts x 2 into 4 ohms
  • 4 ohm - 16 ohm stable (speakers A or B)
  • 8 ohm - 16 ohm stable (speakers A + B)
• Frequency response: 10-100,000 Hz (+1dB, -3 dB)
• Signal-to-noise ratio: 106 dB
• Front-panel A/B speaker switching
• High-current Class AB amplifier design

Connections and controls:

• Stereo balanced XLR
• Unbalanced RCA inputs
• Rear-panel input control switch
• Front-panel power meters show the instantaneous peaks in the signal for each channel
• Front-panel backlight control button
• Rear-panel 12-volt trigger input for control from other devices (mono mini-cable included)
• Copper binding post terminals accept bare wire, banana plugs, and spade lugs

Warranty and dimensions:

• 17.1"W x 5.3"H x 113.66"D
• Weight: 25.1 lbs.
• Warranty: 2 years
• Our 30-day money back guarantee

What's In The Box:

• Stereo power amp
• 6' AC power cord
• 6' Mono-minijack cable
• Initial Setup Guide
• Warranty/Product Registration
• Safety Information
• Owners manual
