Rotel RC-1590 MKII Stereo Preamplifier with Built-in DAC and Bluetooth

The RC-1590MKII is a reference level preamplifier delivering an unprecedented level of acoustic audio performance. This preamplifier includes support for all popular source inputs including analog, digital, PC-USB with MQA, wireless aptX HD and AAC Bluetooth streaming, XLR Balanced, iPod USB and a Moving Magnet Phono stage. The dual, in-house manufactured, toroidal transformers isolate power to all critical analog and digital circuits delivering an ultra-low noise floor and reduced distortion. A premium Texas Instruments DAC with supporting acoustically tuned audio circuits ensure the RC-1590MKII sets a new standard for Rotel products.

Product Highlights:

• Stereo preamplifier with digital and analog inputs to handle a variety of music sources
• Premium Texas Instruments 32-bit/384kHz digital to analog converter
• Dual custom-built toroidal transformers provide isolated power supplies for analog and digital signal paths
• Frequency response: 10-100,000 Hz (line inputs, ±0.1dB); 20-20,000 Hz (phono input, ±0.2dB); 20-20,000 Hz (digital inputs, ±0.5dB)
• Signal-to-noise ratio: 117 dB (line); 80 dB (phono); 117 dB (digital)
• Total harmonic distortion: 0.002%
• Support for MQA and MQA Studio files
• Roon tested
• Dimmable front-panel display
• Remote control

Connections:

• 4 unbalanced stereo RCA inputs
  • Dedicated phono input for turntables with moving magnet cartridges
• Balanced stereo XLR input
• 3 optical digital and 3 coaxial digital inputs (up to 24-bit/192kHz resolution)
• USB Type-B input for connecting a computer (PCM up to 32-bit/384kHz resolution)
• USB Type-A port on front panel handles audio signals from an iPod®, iPhone®, or iPad®
• Dual stereo RCA preamp outputs
• Dual stereo XLR outputs
• 1 optical digital and 1 coaxial digital audio output
• Dual mono RCA subwoofer outputs
• Front-panel 3.5mm headphone output
• Rotel Link input/output
  • Allows connected Rotel products to communicate with each other and be controlled via the Rotel app
• 3.5mm IR input
• Dual 3.5mm 12-volt trigger outputs
• Ethernet port connects the amp to your home network for software updates and integration with 3rd-party control systems
• RS-232 port for use with home automation control systems, like Crestron

Dimensions and warranty:

• 17-1/16"W x 5-3/4"H x 15-1/8"D (3U rack spaces; rack ears available separately from the manufacturer)
• Weight: 22.3 lbs.
• Warranty: 5 years
• Our 30-day money back guarantee
• Black MFR # ROT1040007
• Silver MFR # ROT1040008

What's In The Box:

• Stereo preamplifier
• 58" AC power cord
• Remote control (RR-AX100)
• 2 "AA" batteries
• 5' USB-B to USB-A cable
• 57" Ethernet cable
• 40 Stereo RCA cable
• Two 40" Stereo minijack cables
• Owner's manual on USB thumbdrive
• Warranty Information
• Important Safety Instructions
